Printing technology
|
Direct Thermal for POS applications |
Resolution
|
203 dpi |
Code pages
|
15 codepages, 17 country tables |
Barcodes
|
Code3of9, UPC-A, UPC-E, EAN-13(JAN-13), EAN-8(JAN-8), ITF, CODE39, CODE128,CODABAR(NW-7), CODE93, PDF 417, QR Code, GS1-Databar, Composit Symbologies
|
Print speed (max.)
|
250 mm/s |
Print width (max.)
|
76mm |
Media width
|
58 to 80mm (+/- 0.5mm) |
Media thickness |
53 to 85 μm |
Roll size (max.)
|
83 mm outside diameter |
Media type
|
Thermal roll |
Media sensor
|
Paper End |
Standard interfaces |
USB 2.0 + LAN 10/100base-T |
USB 2.0 + Serial RS232C (1200-115200 baud) |
Case, mechanism
|
Stylish fl at-top case and top loading mechanism |
Control panel
|
Two buttons, two LEDs |
NV fl ash memory
|
8 MB |
Cutter
|
Guillotine type, full and partial cut |
Drawer kick-out |
CDK / DK connector, RJ12, 2 drawer control |
Emulations |
ESC/POS ®™ |
Drivers and software
|
Windows, Android, Apple iOS & MacOSX, Linux |
Size (WxDxH),weight |
140x195x132 mm, 1.9 Kg |
Power supply |
100 – 240v, 50-60 Hz, external power supply (supplied) or 24V DC |
Reliability |
150Kms / 1 million cuts |
EHC and safety standards |
CE, TUV, UL, cUL, FCC, VCCI |
