Item | Specification |
CPU |
Intel® Celeron® J1900 (2M Cache, up to 2.42 GHz)
|
Intel® Core™ i3-3217UE (3M Cache, 1.60 GHz)
|
Intel® Core™ i7-3517UE (4M Cache, up to 2.80 GHz) |
Main |
Memory |
DDR3 SODIMM 2GB (up to 8GB by 2 x Slots) |
Storage |
2.5" SATA-? 320GB HDD & SSD(64GB/128GB) |
Primary Display |
LCD |
15-inch TFT LCD (250cd), W / LED Back-light, LVDS Interface |
Resolution |
1024 x 768 |
Touch |
15-inch 5-wire Resistive , Serial interface |
|
Speaker |
1 x 1W |
USB |
6 x USB (Rear: 4 x USB, Side: 2 x USB) |
Serial |
4 x RS-232C (3 x Powered DSUB-9, 1 x RJ-45) |
PS/2 |
1 x Keyboard or Mouse |
LAN |
1 x Gigabit LAN |
VGA |
1 x RGB |
Audio |
2 ports (1 x Mic-in, 1 x Line-out) |
Power |
DC-IN |
External 60/72W Adapter |
Input AC 100~240V/50~60Hz, Output DC 12V/5A or 6A |
User Environment |
Temperature |
Operating -25? to 65?, Storage -35? to 75? |
Size |
Dimension |
341 x 345 x 209 mm (W x D x H) |
Weight |
6.6kg |
Optional Peripherals |
MSR |
ISO 1,2,3 Tracks Reading |
SCR |
EMV level 1, 2 |
OS |
POSReady2009 / POSReady7 |
2nd Display |
15-inch TFT LCD (1024 x 768), W / LED Back-light (Touch or Non-Touch) |
9.7-inch TFT LCD (1024 x 768), W / LED Back-light (Touch or Non-Touch) |
CDP |
VFD (20 columns x 2 lines) |
Dallas |
Dallas I-button Reader |
Cash Drawer Port |
Serial trigger |
