Mechanical |
|
Dimensions (LxWxH) |
104 mm x 71 mm x 160 mm (4.1? x 2.8? x 6.3?) |
Weight |
147 g (5.2 oz) |
Electrical |
|
Input Voltage |
4 VDC to 5.5 VDC |
Operating Power |
2.3 W (450mA @ 5 VDC) |
Standby Power |
0.45 W (90mA @ 5 VDC) |
Host System Interfaces |
USB, Keyboard Wedge, RS232, IBM 46xx (RS485) |
Environmental |
|
Operating Temperature |
0°C to 50°C (32°F to 122°F) |
Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
Humidity |
0% to 95% relative humidity, non-condensing |
Drop |
Designed to withstand 50 1.8 m
(6/) drops to concrete Ratchet stand: Designed to withstand 50 1.2 m
(4/) drops to concrete on each of the faces |
Environmental Sealing |
IP41 |
Light Levels |
0 to 100,000 lux (9,290 foot-candles) |
Ratchet Cycles |
The ratchet stand shall support
10,000 cycles (each cycle is one full movement of the scanner either up
or down) without losing its ability to keep the scanner in any ratchet
position |
Scan Performance |
|
Scan Pattern |
Area Image (838 x 640 pixel array) |
Motion Tolerance |
Up to 610 cm/s (240 in/s) for 13 mil UPC at optimal focus |
Scan Angle |
HD Focus: Horizontal 41.4°; Vertical: 32.2° SR Focus: Horizontal: 42.4°; Vertical: 33° ER Focus: Horizontal: 31.6°; Vertical: 24.4° |
Symbol Contrast |
20% minimum reflectance difference |
Pitch, Skew |
45°, 65° |
Decode Capability |
Reads standard 1D, stacked, 2D and postal symbologies; limited OCR font reading |
