Specifications |
Protocols/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS
(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE,
LLDPMED, LDAP, TR-069, 802.1x, TLS, SRTP |
Network Interfaces |
Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE |
Graphic Display |
132 x 48 backlit graphical LCD display |
Feature Keys |
2 line keys with dual-color LED and 2 SIP accounts, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 13
dedicated function keys for MUTE, HEADSET, TRANSFER, CONFERENCE, SEND
and REDIAL, SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD,
PAGE/INTERCOM, RECORD, HOME |
Voice Codecs |
Support for G.711µ/a, G.722 (wide-band), G.723, G.726-32, G.729 A/B,
iLBC, inband and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD,
CNG, AEC, PLC, AJB, AGC |
Telephony Features |
Hold, transfer, forward (unconditional/no-answer/busy), 3-way
conferencing, call park/pickup, shared-call appearance (SCA) /
bridged-line-appearance (BLA), Downloadable phone book (XML, LDAP, up to
500 items), call waiting, call history (up to 200 records), off-hook
auto dial, auto answer, click-to-dial, flexible dial plan, hot desking,
personalized music ringtones, server redundancy & fail-over |
Headset Jack |
RJ9 headset jack |
HD Audio |
Yes, HD handset and speakerphone with support for wideband audio |
Base Stand |
Yes, 2 angled positions available, wall mountable |
Wall Mountable |
Yes |
QoS |
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS |
Security |
User and administrator level access control, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, TLS, SRTP,
HTTPS, 802.1x media access control |
Multi-language |
English, German, Italian, French, Spanish, Portuguese, Russian,
Croatian, simplified and traditional Chinese, Korean, Japanese and more |
Upgrade/Provisioning |
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file |
Power & Green Energy Efficiency |
Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA PoE: IEEE802.3af Class 2, 3.84W-6.49W |
Physical |
Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset) |
Temperature and Humidity |
Operation: 0°C to 40°C, Storage: -10°C to 60°C , Humidity: 10% to 90% Non-condensing |
Package Content |
GXP1625 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License |
Compliance |
FCC: Part 15 (CFR 47) Class B CE: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1 RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1 |
