Specifications |
Air Interface |
Telephony standards: DECT EN 301 406:2001 DECT GAP TBR22 EN 300 444:2001 DECT WRS EN 300 700 CAT-iq TS 102 527 Frequency bands: 1880 – 1900 MHz Number of Channels: 10 (Europe) Range: up to 300 meters outdoors and 50 meters indoors |
Peripherals |
5 LED indicators: Power, Network, Association, Activity, DECT Signal Strength Reset button, Dissociation button One 10/100 Mbps auto-sensing Ethernet port with integrated PoE |
Protocol/Standards |
TCP/IP/UDP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, PPPoE, SSH, TFTP, NTP, LLDP-MED, UPnP |
Voice Codecs |
G.722 codec for HD audio and G.726 codec for narrow band audio |
Telephony Features |
Plug-n-Play, auto association, auto region detection and seamless call handover |
Security |
User and administrator level access control, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, HTTPS, 802.1x
media access control |
Multi-language |
Arabic, Chinese Simple, Chinese Tradition, Czech, Dutch, English,
French, German, Hebrew, Italian, Japanese, Korean, Polish, Portuguese,
Russian, Serbian, Slovakian, Spanish, Swedish, Turkish |
Upgrade/Provisioning |
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using AES encrypted XML configuration file |
Association |
Up to 5 repeaters in star Relays up to 2 concurrent HD calls Automatic or manual association to base station |
Power & Green Energy Efficiency |
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection; PoE: IEEE802.3af Class 1, 0.44W–3.84W |
Dimensions |
28.5(H) x 130(W) x 90(D) mm |
Package Content |
Repeater Unit Universal Power Supply Ethernet cable Quick Start Guide GPL statement |
Weight |
Repeater Unit: 143g Universal Power Supply: 50g Package: 360g |
Temperature and Humidity |
Operation: -10?C to 50?C (14?F to 122?F) Storage: -20?C to 60?C (-4?F to 140?F) Humidity: 10% to 90% non-condensing |
Compliance |
FCC: FCC Part 15B, FCC Part 15D, MPE CE: EN 60950-1, EN 301 489-1, EN 301 489-6, EN 301 406, EN 50385, EN 55032, EN 55024, EN 61000-3-2, EN 61000-3-3 RCM: AS/NZS 60950.1 ANATEL |
