Specifications |
Air Interface |
Telephony standards: DECT Number of Channels: 10 (Europe) Range: up to 300 meters outdoors and 50 meters |
Peripherals |
5 LED indicators: Power, Network, Register, Call, DECT Reset button, Pairing/Paging button One 10/100 Mbps auto-sensing Ethernet port with integrated PoE |
Protocol/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS
(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE,
LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6 (Pending) |
Voice Codecs |
G.711μ/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS,
G.722.2/AMR-WB (special order), in-band and out-of-band DTMF (in audio,
RFC2833, SIP INFO), VAD, CNG, PLC, AJB |
Telephony Features |
Hold, transfer, forward, 3-way conference, downloadable phonebook
(XML, LDAP, up to 3000 entries), call waiting, call log (up to 300
records), auto answer, flexible dial plan, music on hold, server
redundancy and fail-over |
Sample Applications |
Weather, Currency (Pending) |
QoS |
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS) |
Security |
User and administrator level access control, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, TLS, SRTP,
HTTPS, 802.1x media access control, DECT authentication & encryption |
Multi-language |
Chinese Simple, Chinese Tradition, Czech, Danish, Dutch, English,
Estonian, Finnish, French, German, Hebrew, Hungarian, Japanese, Korean,
Norwegian, Portuguese, Romanian, Spanish, Swedish, Turkish |
Upgrade/Provisioning |
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file |
Multiple SIP Accounts |
Up to ten (10) distinct SIP accounts per system Each handset may map to any SIP account(s) Each SIP account may map to any handset(s) |
Ring Group |
Flexible options when multiple handsets share the same SIP account Circular Mode: all phones ring sequentially from the phone next to the one that answered last Linear Mode: all phones ring sequentially in the predesignated order Parallel Mode: all phones ring concurrently and after one phone answers, the remaining available phones can make new calls Shared Mode: all phones ring concurrently and always share the same line similar to analog phones |
Power & Green Energy Efficiency |
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection; PoE: IEEE802.3af Class 1, 0.44W–3.84W |
Dimensions |
28.5(H) x 130(W) x 90(D) mm |
Package Content |
Base Unit Universal Power Supply Ethernet cable Quick Start Guide GPL statement |
Temperature and Humidity |
Operation: -10°C to 50°C (14°F to 122°F) Storage: -20°C to 60°C (-4°F to 140°F) Humidity: 10% to 90% non-condensing |
Compliance |
FCC: Part 15D, Part 15B CE: EN60950, EN301489-1-6, EN301406 RCM: AS/NZS60950 ANATEL: #2288-16-9452 |
