| Protocols/Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDPMED, LDAP, TR-069, 802.1x, TLS, SRTP |
| Network Interfaces | Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE |
| Graphic Display | 132 x 48 LCD display |
| Feature Keys | 2 line keys with dual-color LED and 1 SIP account,
3 XML programmable context sensitive soft keys,
5 (navigation, menu) keys.
13 dedicated function keys for PAGE/INTERCOM, PHONEBOOK, MESSAGE, HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME |
| Voice Codecs | Support for G.711µ/a, G.722 (wide-band), G.723,G.726-32, G.729 A/B, iLBC, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO) |
| Telephony Features | Hold, transfer, forward (unconditional/no-answer/busy),
3-way conferencing, call park/pickup,
downloadable phone book (XML, LDAP, up to 500 items),
call waiting, call history (up to 200 records),
off-hook auto dial, auto answer, click-to-dial, flexible dial plan,
hot desking, personalized music ringtones, server redundancy & fail-over |
| Headset Jack | RJ9 headset jack |
| Base Stand | Yes, 2 angled positions available, wall mountable |
| Wall Mountable | Yes |
| QoS | Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security | User and administrator level access control,
MD5 and MD5-sess based authentication,
256-bit AES encrypted configuration file, TLS,
SRTP, HTTPS, 802.1x media access control |
| Multi-language | English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese and more |
| Upgrade/Provisioning | Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR- 069 or AES encrypted XML configuration file |
| Power & Green Energy Efficiency | Universal Power Supply Input 100-240VAC 50-60Hz;
Output +5VDC, 600mA |
| Physical | Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) |
| Temperature and Humidity | Operation: 0°C to 40°C,
Storage: -10°C to 60°C,
Humidity: 10% to 90% Non-condensing |
| Package Content | GXP1610/1615 phone,
Handset with cord,
Base stand,
Universal power supply,
Network cable,
Quick Installation Guide,
Brochure,
GPL License |
| Compliance | FCC: Part 15 (CFR 47) Class B
CE: EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1 |
