Model |
2201L |
Form factor |
Desktop |
Display |
22" diagonal, Active matrix TFT LCD with LED backlights |
Aspect ratio |
16:9 Widescreen |
Useful screen area |
Horizontal: 18.8" (477 mm) Vertical: 10.6" (268 mm) |
Monitor dimensions (with stand) |
Width: 21.7" (551 mm) Height: 15.4" 392 mm) Depth: 7.6" (193 mm) |
Native (optimal) resolution |
1920x1080 |
Other supported resolutions |
640x480 60Hz 720x576 50Hz 800x600 56, 60Hz 1024x768 60Hz 1280x720 50, 60Hz 1280x960 60Hz 1280x1024 60Hz 1366x768 60Hz 1440x900 60Hz 1680x1050 60Hz 1920x1080 50, 60Hz |
Colors |
16.7 million |
Brightness (typical) |
LCD panel: 250 nits iTouch: 225 nits IntelliTouch Plus: 225 nits PCAP: 225 nits |
Response time - total (typical) |
5 msec |
Viewing angle (typical) |
Horizontal: ±85° or 170° total Vertical: ±80° or 160° total |
Contrast ratio (typical) |
1000:1 |
On-screen display (OSD) |
Controls: Menu, Up, Down, Select Settings:
Brightness, Contrast, Clock, Phase, H-position, Vposition, Auto-Adjust,
Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language,
OSD Rotation, Volume, Mute, Recall Defaults, Video Source Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese Lockouts: OSD, Power |
Input Video
|
Analog VGA on Female DE-15 connector Digital DVI on Female DVI-D connector Horizontal Sync Frequency Range: 32-80KHz Vertical Sync Frequency Range: 50-75 Hz |
Power supply |
DC (external power adapter included with unit) |
Input voltage |
AC/DC Adapter: 100-240 VAC, 50/60 Hz Monitor: 12 VDC ±5% |
Input connector |
AC/DC Adapter: IEC 60320 C14 Monitor: Coaxial power jack (2 mm pin diameter, 6.5 mm barrel diameter, 10 mm barrel length) |
Power consumption (typical) |
29W |
---|
