Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 44/2002 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100mW e.i.r.p.
Στην
ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της
κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 44/2002
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
| Specifications |
| Protocols/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS(A
record, SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPV6 |
| Network Interfaces |
Dual switched auto-sensing 10/100Mbps ethernet ports with integrated POE |
| Graphic Display |
200 x 80 pixel backlit LCD display |
| WiFi |
Yes, integrated dual-band WiFi 802.11 a/b/g/n/ac (2.4Ghz & 5Ghz) |
| Bluetooth |
No |
| Feature Keys |
6 line keys with up to 3 SIP accounts,
4 XML programmable context sensitive softkeys,
5 navigation/menu keys,
8 dedicated function keys for: PHONEBOOK, TRANSFER, CONFERENCE, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOLUME |
| Voice Codecs |
Support for G.729A/B, G.711μ/a-law, G.726, G.722 (wide-band), G.723,
iLBC, OPUS, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO),
VAD, CNG, AEC, PLC, AJB, AGC |
| Auxiliary Ports |
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, and a
sepa- rate EHS port reserved for external EHS adapter in the future |
| Telephony Features |
Hold, transfer, forward, 5-way conference, call park, call pickup,
sharedcall-appearance(SCA)/bridged-line-appearance(BLA), downloadable
phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 500
records), XML customization of screen, off-hook auto dial, auto answer,
click-to-dial, flexible dial plan, hot desking, personalized music
ringtones and music on hold, server redundancy and fail-over |
| HD Audio |
Yes, HD handset and speakerphone with support for wideband audio |
| Base Stand |
Yes, 2 angle positions available. Wall Mount stand sold separately |
| QoS |
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security |
User and administrator level passwords, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, SRTP, TLS,
802.1x media access control, Kensington Security Slot (Kensington Lock)
support |
| Multi-language |
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean, Japanese |
| Upgrade/Provisioning |
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file |
| Power & Green Energy Efficiency |
Universal power adapter included:
Input:100-240V; Output: +5V, 2A;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 5W |
| Dimensions |
231mm(W) x 167mm(L) x 86mm(H) |
| Temperature and Humidity |
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing |
| Package Content |
GXP1760W phone,
Handset with cord,
Base stand,
Universal power supply,
Network cable,
Quick Installation Guide,
GPL license |
| Compliance |
FCC: Part 15 (CFR 47) Class B
CE: EN55022 Class B; EN55024 Class B;EN61000-3-2; EN61000-3-3;EN60950-1
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950.1 |
|
